Universal Tool UT8749ADG Angle Die Grinder

Angle Die Grinder

UT8749ADG

Universal Tool UT8749ADG Angle Die Grinder features an ultra heavy-duty angle head, alloy steel spiral gears, 1.0 HP stall-resistant motor, insulated composite grip, lock-off throttle, and rear exhaust. Ideal for continuous grinding.

Safety Manual
Manual Parts
Fact Sheet
Request Info
Order Parts

SHARE

Product Details

  • Unique ultra heavy duty angle head and alloy steel spiral gear & pinion for extra reliability
  • Head height 2.5″ from the top of angle head to the face of collet lock nut.
  • 1.0 HP motor for added stall resistance.
  • Insulated composite grip; reduces weight and operator fatigue, lock-off throttle lever.
  • Rear exhaust.
  • 1/4-in. Collet size
  • Best for: Continuous grinding and sanding 2″ & 3″ Disc

Specifications

Additional information

collet-size-in

1/4-in.
Motor (HP)

1
Motor (kw)

0.73
max-wheel-size-in

3
Speed (RPM)

12000
Exhaust

Rear
weight-lbs

3
Weight (kg)

1.3
Length (in.)

10.5
Length (mm)

266
Air Inlet (NPT / BSP)

1/4-in.
Rec. Hose Size (in)

3/8-in.
Air Consumption (cfm)

16
Average Air Consumption (CFM)

4
Rec. Air Pressure

90 psi-6.2 bar

Universal Tool UT8749ADG Angle Die Grinder features an ultra heavy-duty angle head, alloy steel spiral gears, 1.0 HP stall-resistant motor, insulated composite grip, lock-off throttle, and rear exhaust. Ideal for continuous grinding.

Additional information

collet-size-in

1/4-in.
Motor (HP)

1
Motor (kw)

0.73
max-wheel-size-in

3
Speed (RPM)

12000
Exhaust

Rear
weight-lbs

3
Weight (kg)

1.3
Length (in.)

10.5
Length (mm)

266
Air Inlet (NPT / BSP)

1/4-in.
Rec. Hose Size (in)

3/8-in.
Air Consumption (cfm)

16
Average Air Consumption (CFM)

4
Rec. Air Pressure

90 psi-6.2 bar
