AIRCAT 3/8″ Impacting Ratchet Wrench

Model: 812-RW

AIRCAT® 812-RW 3/8-inch reaction-less ratchets feature an internal impact mechanism that eliminates torque reaction and risk of finger trapping. Each air tool delivers 80 ft-lbs of maximum torque and 350 RPM free speed.

Safety Manual Manual / Parts Fact Sheets Request Info Order Parts

Product Details +

80 ft-lb Maximum torque
350 RPM run-down speed with built-in regulator for control
Internal impact mechanism eliminates torque reaction and risk of finger trapping
Very quiet compared to conventional air ratchets – only (79 dBA)
Composite handle grip increases operating comfort
Needle bearing construction increases reliability
Push and lock forward/reverse switch

Specifications +

Maximum Torque (ft-lbs)	80
Working Torque (ft-lbs)	12-55
Free Speed (RPM)	350
Square Drive (in.)	3/8-in.
Bolt Capacity (in.)	1/2-in.
Weight (lbs.)	2.9
Length (in.)	10-in.
Noise Levels d(B)A	88
Vibration Levels (m/sec2)	5.7
Air Consumption (CFM)	4
Air Inlet (NPT/BSP)	1/4-in.
Rec. Hose Size (in.)	3/8-in.
