TCT Cutters (concrete)
4.4 m/s2 (K=+1.43m/s2)
TCT Cutters (steel)
2.9 m/s2 (K=+0.63m/s2)
Star Cutters (concrete)
3.7m/s2 (K=+0.7m/s2)
Star Cutters (steel)
3.8m/s2 (K=+0.98m/s2)
Beam Cutters (concrete)
4.8m/s2 (K=+0.79m/s2)
Beam Cutters (steel)
5.4m/s2 (K=+0.9m/s2)
Milling Cutters (concrete)
7.0m/s2 (K=+1.41m/s2)
Milling Cutters (steel)
4.8m/s2 (K=+1.3m/s2)
| Height (mm) | 900 |
|---|---|
| Width (mm) | 350 |
| Cutting Width (mm) | 195 |
| Length (mm) | 900 |
| Weight (kg) | 68 |
| Cutter Head Speed | 1650 rpm |
| Working Distance from wall | 55 mm |
| Air Consumption (cfm) | 38 – 80 |
| Vibration Level (Aeq m/s2) | 23.1 |
| Voltage | 230 |
| Cycle | 50 / 60 |
| Removal Rate | 30m 2/hr (323ft 2/hr) |
| Cable Size (mm) | Min 2.5 core |
| Cable Length (m) | 30 |
| Power (hp-kw) | 3-2.2 |
| Vibration Level | 4.4 |
| Maximum Cutting Depth (mm) | 3 |
| Vacuum Take off diameter | 50 |
